Training a Model on Multiple GPUs with Data Parallelism

import dataclasses

import os

import datasets

import tqdm

import tokenizers

import torch

import torch.distributed as dist

import torch.nn as nn

import torch.nn.functional as F

import torch.optim.lr_scheduler as lr_scheduler

from torch import Tensor

from torch.nn.parallel import DistributedDataParallel as DDP

from torch.utils.data.distributed import DistributedSampler

# Build the model

@dataclasses.dataclass

class LlamaConfig:

“”“Define Llama model hyperparameters.”“”

vocab_size: int = 50000# Size of the tokenizer vocabulary

max_position_embeddings: int = 2048# Maximum sequence length

hidden_size: int = 768# Dimension of hidden layers

intermediate_size: int = 4*768# Dimension of MLP’s hidden layer

num_hidden_layers: int = 12# Number of transformer layers

num_attention_heads: int = 12# Number of attention heads

num_key_value_heads: int = 3# Number of key-value heads for GQA

class RotaryPositionEncoding(nn.Module):

“”“Rotary position encoding.”“”

def __init__(self, dim: int, max_position_embeddings: int) -> None:

“”“Initialize the RotaryPositionEncoding module

Args:

dim: The hidden dimension of the input tensor to which RoPE is applied

max_position_embeddings: The maximum sequence length of the input tensor

““”

super().__init__()

self.dim = dim

self.max_position_embeddings = max_position_embeddings

# compute a matrix of ntheta_i

N = 10_000.0

inv_freq = 1.0 / (N ** (torch.arange(0, dim, 2) / dim))

inv_freq = torch.cat((inv_freq, inv_freq), dim=–1)

position = torch.arange(max_position_embeddings)

sinusoid_inp = torch.outer(position, inv_freq)

# save cosine and sine matrices as buffers, not parameters

self.register_buffer(“cos”, sinusoid_inp.cos())

self.register_buffer(“sin”, sinusoid_inp.sin())

def forward(self, x: Tensor) -> Tensor:

“”“Apply RoPE to tensor x

Args:

x: Input tensor of shape (batch_size, seq_length, num_heads, head_dim)

Returns:

Output tensor of shape (batch_size, seq_length, num_heads, head_dim)

““”

batch_size, seq_len, num_heads, head_dim = x.shape

dtype = x.dtype

# transform the cosine and sine matrices to 4D tensor and the same dtype as x

cos = self.cos.to(dtype)[:seq_len].view(1, seq_len, 1, –1)

sin = self.sin.to(dtype)[:seq_len].view(1, seq_len, 1, –1)

# apply RoPE to x

x1, x2 = x.chunk(2, dim=–1)

rotated = torch.cat((–x2, x1), dim=–1)

output = (x * cos) + (rotated * sin)

return output

class LlamaAttention(nn.Module):

“”“Grouped-query attention with rotary embeddings.”“”

def __init__(self, config: LlamaConfig) -> None:

super().__init__()

self.hidden_size = config.hidden_size

self.num_heads = config.num_attention_heads

self.head_dim = self.hidden_size // self.num_heads

self.num_kv_heads = config.num_key_value_heads# GQA: H_kv < H_q

# hidden_size must be divisible by num_heads

assert (self.head_dim * self.num_heads) == self.hidden_size

# Linear layers for Q, K, V projections

self.q_proj = nn.Linear(self.hidden_size, self.num_heads * self.head_dim, bias=False)

self.k_proj = nn.Linear(self.hidden_size, self.num_kv_heads * self.head_dim, bias=False)

self.v_proj = nn.Linear(self.hidden_size, self.num_kv_heads * self.head_dim, bias=False)

self.o_proj = nn.Linear(self.num_heads * self.head_dim, self.hidden_size, bias=False)

def forward(self, hidden_states: Tensor, rope: RotaryPositionEncoding, attn_mask: Tensor) -> Tensor:

bs, seq_len, dim = hidden_states.size()

# Project inputs to Q, K, V

query_states = self.q_proj(hidden_states).view(bs, seq_len, self.num_heads, self.head_dim)

key_states = self.k_proj(hidden_states).view(bs, seq_len, self.num_kv_heads, self.head_dim)

value_states = self.v_proj(hidden_states).view(bs, seq_len, self.num_kv_heads, self.head_dim)

# Apply rotary position embeddings

query_states = rope(query_states)

key_states = rope(key_states)

# Transpose tensors from BSHD to BHSD dimension for scaled_dot_product_attention

query_states = query_states.transpose(1, 2)

key_states = key_states.transpose(1, 2)

value_states = value_states.transpose(1, 2)

# Use PyTorch’s optimized attention implementation

# setting is_causal=True is incompatible with setting explicit attention mask

attn_output = F.scaled_dot_product_attention(

query_states,

key_states,

value_states,

attn_mask=attn_mask,

dropout_p=0.0,

enable_gqa=True,

)

# Transpose output tensor from BHSD to BSHD dimension, reshape to 3D, and then project output

attn_output = attn_output.transpose(1, 2).reshape(bs, seq_len, self.hidden_size)

attn_output = self.o_proj(attn_output)

return attn_output

class LlamaMLP(nn.Module):

“”“Feed-forward network with SwiGLU activation.”“”

def __init__(self, config: LlamaConfig) -> None:

super().__init__()

# Two parallel projections for SwiGLU

self.gate_proj = nn.Linear(config.hidden_size, config.intermediate_size, bias=False)

self.up_proj = nn.Linear(config.hidden_size, config.intermediate_size, bias=False)

self.act_fn = F.silu# SwiGLU activation function

# Project back to hidden size

self.down_proj = nn.Linear(config.intermediate_size, config.hidden_size, bias=False)

def forward(self, x: Tensor) -> Tensor:

# SwiGLU activation: multiply gate and up-projected inputs

gate = self.act_fn(self.gate_proj(x))

up = self.up_proj(x)

return self.down_proj(gate * up)

class LlamaDecoderLayer(nn.Module):

“”“Single transformer layer for a Llama model.”“”

def __init__(self, config: LlamaConfig) -> None:

super().__init__()

self.input_layernorm = nn.RMSNorm(config.hidden_size, eps=1e–5)

self.self_attn = LlamaAttention(config)

self.post_attention_layernorm = nn.RMSNorm(config.hidden_size, eps=1e–5)

self.mlp = LlamaMLP(config)

def forward(self, hidden_states: Tensor, rope: RotaryPositionEncoding, attn_mask: Tensor) -> Tensor:

# First residual block: Self-attention

residual = hidden_states

hidden_states = self.input_layernorm(hidden_states)

attn_outputs = self.self_attn(hidden_states, rope=rope, attn_mask=attn_mask)

hidden_states = attn_outputs + residual

# Second residual block: MLP

residual = hidden_states

hidden_states = self.post_attention_layernorm(hidden_states)

hidden_states = self.mlp(hidden_states) + residual

return hidden_states

class LlamaModel(nn.Module):

“”“The full Llama model without any pretraining heads.”“”

def __init__(self, config: LlamaConfig) -> None:

super().__init__()

self.rotary_emb = RotaryPositionEncoding(

config.hidden_size // config.num_attention_heads,

config.max_position_embeddings,

)

self.embed_tokens = nn.Embedding(config.vocab_size, config.hidden_size)

self.layers = nn.ModuleList([LlamaDecoderLayer(config) for _ in range(config.num_hidden_layers)])

self.norm = nn.RMSNorm(config.hidden_size, eps=1e–5)

def forward(self, input_ids: Tensor, attn_mask: Tensor) -> Tensor:

# Convert input token IDs to embeddings

hidden_states = self.embed_tokens(input_ids)

# Process through all transformer layers, then the final norm layer

for layer in self.layers:

hidden_states = layer(hidden_states, rope=self.rotary_emb, attn_mask=attn_mask)

hidden_states = self.norm(hidden_states)

# Return the final hidden states

return hidden_states

class LlamaForPretraining(nn.Module):

def __init__(self, config: LlamaConfig) -> None:

super().__init__()

self.base_model = LlamaModel(config)

self.lm_head = nn.Linear(config.hidden_size, config.vocab_size, bias=False)

def forward(self, input_ids: Tensor, attn_mask: Tensor) -> Tensor:

hidden_states = self.base_model(input_ids, attn_mask)

return self.lm_head(hidden_states)

def create_causal_mask(batch: Tensor, dtype: torch.dtype = torch.float32) -> Tensor:

“”“Create a causal mask for self-attention.

Args:

batch: Batch of sequences, shape (batch_size, seq_len)

dtype: Data type of the mask

Returns:

Causal mask of shape (seq_len, seq_len)

““”

batch_size, seq_len = batch.shape

mask = torch.full((seq_len, seq_len), float(‘-inf’), device=batch.device, dtype=dtype)

.triu(diagonal=1)

return mask

def create_padding_mask(batch: Tensor, padding_token_id: int, dtype: torch.dtype = torch.float32) -> Tensor:

“”“Create a padding mask for a batch of sequences for self-attention.

Args:

batch: Batch of sequences, shape (batch_size, seq_len)

padding_token_id: ID of the padding token

dtype: Data type of the mask

Returns:

Padding mask of shape (batch_size, 1, seq_len, seq_len)

““”

padded = torch.zeros_like(batch, device=batch.device, dtype=dtype)

.masked_fill(batch == padding_token_id, float(‘-inf’))

mask = padded[:,:,None] + padded[:,None,:]

return mask[:, None, :, :]

# Generator function to create padded sequences of fixed length

class PretrainingDataset(torch.utils.data.Dataset):

def __init__(self, dataset: datasets.Dataset, tokenizer: tokenizers.Tokenizer,

seq_length: int):

self.dataset = dataset

self.tokenizer = tokenizer

self.seq_length = seq_length

self.bot = tokenizer.token_to_id(“[BOT]”)

self.eot = tokenizer.token_to_id(“[EOT]”)

self.pad = tokenizer.token_to_id(“[PAD]”)

def __len__(self):

return len(self.dataset)

def __getitem__(self, index):

“”“Get a sequence of token ids from the dataset. [BOT] and [EOT] tokens

are added. Clipped and padded to the sequence length.

““”

seq = self.dataset[index][“text”]

tokens: list[int] = [self.bot] + self.tokenizer.encode(seq).ids + [self.eot]

# pad to target sequence length

toklen = len(tokens)

if toklen < self.seq_length+1:

pad_length = self.seq_length+1 – toklen

tokens += [self.pad] * pad_length

# return the sequence

x = torch.tensor(tokens[:self.seq_length], dtype=torch.int64)

y = torch.tensor(tokens[1:self.seq_length+1], dtype=torch.int64)

return x, y

# Load the tokenizer

tokenizer = tokenizers.Tokenizer.from_file(“bpe_50K.json”)

# Load the dataset

dataset = datasets.load_dataset(“HuggingFaceFW/fineweb”, “sample-10BT”, split=“train”)

# Initialize the distributed environment

dist.init_process_group(backend=“nccl”)

rank = dist.get_rank()

local_rank = int(os.environ[“LOCAL_RANK”])

world_size = dist.get_world_size()

device = torch.device(f“cuda:{local_rank}”)

print(f“World size: {world_size}, Rank: {rank}, Local rank: {local_rank}. Using device: {device}”)

#torch.cuda.set_device(local_rank)

#torch.set_default_device(device)

# Create pretraining model with default config, then wrap it in DDP

model_config = LlamaConfig()

model = LlamaForPretraining(model_config).to(rank)

model = DDP(model, device_ids=[local_rank])# , output_device=local_rank)

model.train()

# print the model size

print(f“Model parameters size: {sum(p.numel() for p in model.parameters()) / 1024**2:.2f} M”)

print(f“Model buffers size: {sum(p.numel() for p in model.buffers()) / 1024**2:.2f} M”)

print(f“Model precision(s): {set([x.dtype for x in model.state_dict().values()])}”)

# Training parameters

epochs = 3

learning_rate = 1e–3

batch_size = 64

seq_length = 512

num_warmup_steps = 1000

PAD_TOKEN_ID = tokenizer.token_to_id(“[PAD]”)

# DataLoader, optimizer, scheduler, and loss function

dataset = PretrainingDataset(dataset, tokenizer, seq_length)

sampler = DistributedSampler(dataset, shuffle=False)

dataloader = torch.utils.data.DataLoader(

dataset,

batch_size=batch_size,

sampler=sampler,

pin_memory=True,# optional

shuffle=False,

num_workers=world_size,

)

optimizer = torch.optim.AdamW(

model.parameters(), lr=learning_rate, betas=(0.9, 0.99), eps=1e–8, weight_decay=0.1

)

num_training_steps = len(dataloader) * epochs

print(f“Number of training steps: {num_training_steps} = {len(dataloader)} * {epochs}”)

warmup_scheduler = lr_scheduler.LinearLR(

optimizer,

start_factor=0.1, end_factor=1.0, total_iters=num_warmup_steps

)

cosine_scheduler = lr_scheduler.CosineAnnealingLR(

optimizer,

T_max=num_training_steps – num_warmup_steps,

eta_min=0

)

scheduler = lr_scheduler.SequentialLR(

optimizer,

schedulers=[warmup_scheduler, cosine_scheduler],

milestones=[num_warmup_steps]

)

loss_fn = nn.CrossEntropyLoss(ignore_index=PAD_TOKEN_ID)

# start training

for epoch in range(epochs):

pbar = tqdm.tqdm(dataloader, desc=f“Epoch {epoch+1}/{epochs}”)

sampler.set_epoch(epoch) # required for shuffling only

for batch_id, batch in enumerate(pbar):

if batch_id % 1000 == 0 and rank == 0:

# checkpoint the model and optimizer state, only on rank 0 process

torch.save({

“model”: model.module.state_dict() if isinstance(model, DDP) else model.state_dict(),

“optimizer”: optimizer.state_dict(),

“scheduler”: scheduler.state_dict(),

“epoch”: epoch,

“batch”: batch_id,

}, f“llama_pretraining_checkpoint.pth”)

# get batched data, move from CPU to GPU

input_ids, target_ids = batch

input_ids = input_ids.to(device)

target_ids = target_ids.to(device)

# create attention mask: causal mask + padding mask

attn_mask = create_causal_mask(input_ids) +

create_padding_mask(input_ids, PAD_TOKEN_ID)

# extract output from model

logits = model(input_ids, attn_mask)

# compute loss: cross-entropy between logits and target, ignoring padding tokens

loss = loss_fn(logits.view(–1, logits.size(–1)), target_ids.view(–1))

# backward with loss and gradient clipping by L2 norm to 1.0

optimizer.zero_grad()

loss.backward()

torch.nn.utils.clip_grad_norm_(model.parameters(), 1.0)

optimizer.step()

scheduler.step()

pbar.set_postfix(loss=loss.item())

pbar.update(1)

pbar.close()

# Save the model

if rank == 0:

torch.save(model.state_dict(), “llama_pretraining_model.pth”)

torch.save(model.base_model.state_dict(), “llama_model.pth”)

# Clean up the distributed environment

dist.destroy_process_group()
